H2-High Pressure Sensor HPS

For high pressure applications and tank systems

Our high pressure sensor HPS was specially designed for the use in hydrogen (H2) applications, such as filling stations and high pressure tanks, as well as measuring and testing technology.

Our HPS sensors are designed for the two nominal pressure ranges of 0 to 500 bar and 0 to 900 bar for measuring system and tank pressure in stationary or mobile applications.

Materials that come into contact with fluids have been selected in accordance with the requirements for use with hydrogen and withstand the high stresses of use in hydrogen environments, even over long service lives. The HPS sensors are certified according to the H2 norms EC79 and HGV 3.1.

For an optimal integration in systems, the sensor is available with analog or digital (SENT/ LIN) output signal.

file_download Download data sheet

FIELDS OF APPLICATION
  • High pressure tanks and reservoirs
  • Filling and refulling stations
  • Measure and testing technology
FEATURES

High-pressure hydrogen measurement up to 900 bar

  • Robust for measuring pressures up to 900 bar
  • Monobloc measuring element with no welds

Very good hydrogen compatibility

  • Use of fluid-compatible materials
  • Burst-proof and long service life
  • Certified according to EC79 and HGV 3.1

Several design variants available

  • Analog output voltage as well as SENT and LIN output
  • Various connection threads, metric and UNF
  • High-pressure sensor with conical sealing
TECHNICAL SPECIFICATION
Measurement range
Nominal pressure 0–500 bis 0–900 bar
Over pressure 750 bar/1050 bar
Burst pressure 1250 bar/1750 bar
Pressure type Relative

Electrical characteristics
Supply voltage 5 V±0.25 V (12 V LIN)
Current consumption max. 10 mA
Output signals SENT, analog, LIN

Mechanical characteristics
Measuring element Monopart with directly applied thick-film
Housing material Stainless steel
Pressure connection M14×1, conical sealing (metal on metal) or 7/16–20 UNF (o-ring)
Thread Male thread
Electrical connection 3-pin MQS connector
Installation position Any
Weight approx. 37 g

Accuracy
Total error Standard accuracy
±1.0 % FS @ 0–50 °C,
±1.5 % FS @ −40–85 °C,
up to ±0.5 % FS @ −40–85 °C

Environmental conditions
Operating temperature range −40–85 °C
Media temperature range −40–85 °C
Media compatibility Hydrogen, air, nitrogen, coolant (DI-water, ethylene glycol)
